Controller QET
- Model
- Safety light curtain controller QET
Item specifics
- Mains input
- AC 100 V～230 V ±15% 50/60 Hz, DC 24 V ±10%
- Overall power consumption
- ≤5 W
- Input voltage
- WC 220 V or WC 110 V
- Output voltage
- DC 12 V or DC 24 V
- Output current
- ≤200 mA
- Output
- One normally open, one normally closed(standard)
- Response time
- ＜20 ms
- Certificate
- ISO, CE, UL ,FCC, TUV
Review
Description
|
Product model
|
|||
|
Controler
|
QET
|
||
Certificate | ISO, CE | ||
|
Features
|
|||||||
|
Mains input
|
AC 100 V～230 V ±15% 50/60 Hz; DC 24 V ±10%
|
||||||
|
Overall power consumption
|
≤5 W
|
||||||
|
Input voltage
|
WC 220 V or WC 110 V
|
||||||
|
Output voltage
|
DC 12 V or DC 24 V
|
||||||
|
Output current
|
≤200 mA
|
||||||
Output form | One normally open, one normally closed (standard configuration) | ||||||
Output contact capacity | 5 A, AC 250 V / DC 30 V (Resistive load) | ||||||
Response time | ＜20 ms | ||||||
Lifetime of relay | ≥1 million times（Electrical Life) | ||||||
|
Mechanical data
|
|||
|
Case material
|
Plastics
|
||
|
Install
|
Installation of guide rail slot
|
||
|
Mode of connection
|
Connect the plug
|
||
|
Maximum wire size
|
0.5 m²
|
||
|
Environmental characteristics
|
|||
|
Work environment temperature
|
-10°C ～ 55°C
|
||
|
Storage temperature
|
-40℃ ～ 70℃
|
||
|
Work ambient humidity
|
35% RH ～ 85% RH
|
||
|
Storage ambient humidity
|
35% RH ～ 95% RH
|
||
|
Level of protection
|
IP20
|
||
Boundary dimension | 145 × 90 × 72 mm | ||
