5m Obstacle Avoidance｜Laser Scanning Radar｜DADISICK
- Model
- LD-05D Series
Item specifics
- Laser Wavelength:
- 905 nm
- Eye-Safe Level:
- Class I
- Working Range:
- 0.05 m - 5 m
- Scan Angle Range:
- 270°
- Measurement Accuracy:
- ±3 mm
- Angular Resolution:
- 0.1° / 0.3°
- Scanning Frequency:
- 15 Hz / 30 Hz
Review
Description
|
Basic Information
|
||
|
Product name
|
Two-dimensional TOF obstacle avoidance LiDAR |
|
|
Product model
|
LD-05DN | LD-05DP |
Work area | 0.05 m ~ 5 m | |
I/O output | NPN | PNP |
|
Features
|
||
|
Laser source
|
905 nm (class I) |
|
|
Scan angle range
|
270° |
|
Scanning frequency | 15 Hz / 30 Hz | |
Angular Resolution | 0.1° / 0.3° | |
Work area | 0.05 m ~ 5 m | |
Self-learning function | Automatic environment scanning, generating area | |
|
Mechanical/electronic parameters
|
||
|
Electrical connections
|
DB15 MALE / SCATTER |
|
|
Supply voltage
|
DC 9 V ~ 28 V |
|
|
Power consumption
|
2 W |
|
|
Switch drive
|
DC 30 V 50 mA MAX |
|
Shell color | Yellow | |
Protection level | IP65 | |
Weight | 150 g, no cable | |
Size (length × width × height) | 50 mm × 50 mm × 76 mm | |
|
Performance
|
||
|
Recognizable object shape
|
Almost any shape |
|
|
Measurement error
|
±3 mm |
|
|
Number of regional groups
|
16 regional groups, each containing 3 regions |
|
|
Interface
|
||
|
USB
|
Micro - USB |
|
|
Input
|
GND/NC × 4 |
|
|
Switch output
|
NPN × 3, device working status indication × 1 |
|
|
Signal output hold time
|
100 ms ~ 10,000 ms (adjustable) typical value 330 ms |
|
Response time | 15 Hz: 67 ms ~ 29,949 ms (adjustable) typical value 134 ms 30 Hz: 33 ms ~ 29,997 ms (adjustable) typical value 66 ms | |
Status Indicator | Status indicator × 1, area group indicator × 3 | |
|
Environmental parameters
|
||
|
Vibration resistant
|
10-55 Hz, amplitude 0.75 mm, XYZ three-axis,2 hours per axis; 50-200 Hz, 196 m/s² (20G), scanning speed 2 min/cycle, XYZ three-axis,2 hours per axis |
|
|
Working temperature
|
-10℃ ~ +55℃ |
|
|
Storage temperature range
|
-30℃ ~ +75℃ |
|
Resistance to ambient light | >15,000 lux | |
DIMENSION
LD05D Series LiDAR Scanner Wiring Method
Power supply, IO multi-core cable
