Safety light curtain QT series accessories for QA-02 swivel fastening brackets
Safety light curtain QT series accessories for QA-02 swivel fastening brackets
Safety light curtain QT series accessories for QA-02 swivel fastening brackets
Safety light curtain QT series accessories for QA-02 swivel fastening brackets
Safety light curtain QT series accessories for QA-02 swivel fastening brackets
Model
QA-02 swivel fastening brackets for QT series

Item specifics

Brand
DADISICK
Material
Stainless steel
Package size (mm)
120 * 80

Review

Description

Safety light curtain QT series accessories for QA-02 swivel fastening brackets
Product List Configuration
Product number
QA-02
Short right angle bracket
2 PCS
Long right angle bracket
2 PCS
Hexagon socket screw M6 * 8
16 PCS
Leaf spring M5
8 PCS
Shockproof rubber particles
8 PCS
Convex nut
 4 PCS
Hexagon socket screw M5 * 10
4 PCS
Package size(mm)
100 * 100
Gross weight (g)
420
The mounting bracket for safety light curtain accessories, as an essential component to ensure the stable installation of safety light barriers on automated production lines and machinery, integrates efficiency, durability, and flexibility into its design. Made of high-strength alloys, this bracket boasts exceptional load-bearing capacity and corrosion resistance, maintaining structural stability and safety in various harsh industrial environments. Light curtains bracket's ingenious structural design, combined with precise surface treatment technology, not only ensures the accurate positioning of mounting holes but also greatly improves the convenience of installation, allowing users to effortlessly and quickly complete the fixing of safety light screens.
Basic information of installation accessories
Product number
QA-01
Material
Short right angle bracket
304 stainless steel
Long right angle bracket
304 stainless steel
Hexagon socket screw M6 * 8
304 stainless steel
Leaf spring M5
Iron nickel plating
Shockproof rubber particles
Iron nickel plating
Convex nut
Iron nickel plating
Hexagon socket screw M5 * 10
Iron nickel plating
QA-02 swivel fastening brackets-3D.STEP
